9923396 - 2007-2012 EDGE/Widetrak LX Service Manual
©2011 Polaris Sales Inc.
SAE Tap Drill Sizes
Metric Tap Drill Sizes
Decimal Equivalents
1/64................................................................ ...............0156
..............1/32 .................... ...............0312 .... 1 mm= .0394"
3/64................................... ...............0469
..............1/16 .................... ...............0625
5/64................................... ...............0781 .... 2 mm = .0787"
..............3/32 .................... ...............0938
7/64................................... ...............1094 .... 3 mm =.1181"
..............1/8 ........ .1250
9/64................................... ...............1406
..............5/32 .................... ...............1563 .... 4 mm = .1575"
11/64................................. ...............1719
..............3/16 .................... ...............1875 .... 5mm= .1969"
13/64................................. ...............2031
..............7/32 .................... ...............2188
15/64................................. ...............2344 .... 6 mm = .2362"
..............1/4 ........ .25
17/64................................. ...............2656 .... 7 mm = .2756"
..............9/32 .................... ...............2813
19/64................................. ...............2969
..............5/16 .................... ...............3125 .... 8mm= .3150"
21/64................................. ...............3281
..............11/32 .................. ...............3438 .... 9 mm = .3543"
23/64................................. ...............3594
..............3/8 ........ .375
25/64................................. ...............3906 .... 10 mm = .3937"
..............13/32 .................. ...............4063
27/64................................. ...............4219 .... 11 mm =.4331"
..............7/16..................... ...............4375
29/64................................. ...............4531
..............15/32 .................. ...............4688.... 12 mm = .4724"
31/64................................. ...............4844
..............1/2 ........ .5 ....................... ............. 13mm = .5118"
33/64................................. ...............5156
..............17/32 .................. ...............5313
35/64................................. ...............5469 .... 14 mm = .5512"
..............9/16 .................... ...............5625
37/64................................. ...............5781 .... 15 mm = .5906"
..............19/32 .................. ...............5938
39/64................................. ...............6094
..............5/8 ........ .625 ................... ............. 16mm=. 6299"
41/64................................. ...............6406
..............21/32 .................. ...............6563.... 17 mm =.6693"
43/64................................. ...............6719
..............11/16 ................... .............. .6875
45/64................................. ...............7031 .... 18 mm = .7087"
..............23/32................... ...............7188
47/64................................. ...............7344 .... 19 mm = .7480"
..............3/4 ........ .75
49/64................................. ...............7656
..............25/32 .................. ...............7813.... 20 mm = .7874"
51/64................................. ...............7969
..............13/16 .................. ...............8125.... 21 mm =.8268"
53/64................................. ...............8281
..............27/32 .................. ...............8438
55/64................................. ...............8594 .... 22 mm = .8661"
..............7/8 ........ .875
57/64................................. ...............8906 .... 23 mm = .9055"
..............29/32 .................. ...............9063
59/64................................. ...............9219
..............15/16................... ...............9375 .... 24 mm = .9449"
61/64................................. ...............9531
..............31/32 .................. ...............9688.... 25 mm = .9843"
63/64................................. ...............9844
..............1 ........... 1.0
Thread Size/ Drill Size Thread Size / Drill Size
#0-80 3/64 1/2-13 27/64
#1-64 53 1/2-20 29/64
#1-72 53 9/16-12 31/64
#2-56 51 9/16-18 33/64
#2-64 50 5/8-11 17/32
#3-48 5/64 5/8-18 37/64
#3-56 45 3/4-10 21/32
#4-40 43 3/4-16 11/16
#4-48 42 7/8-9 49/64
#5-40 38 7/8-14 13/16
#5-44 37 1-8 7/8
#6-32 36 1-12 59/64
#6-40 33 1 1/8-7 63/64
#8-32 29 1 1/8-12 1 3/64
#8-36 29 1 1/4-7 1 7/64
#10-24 24 1 1/4-12 1 11/64
#10-32 21 1 1/2-6 1 11/32
#12-24 17 1 1/2-12 1 27/64
#12-28 4.6mm 1 3/4-5 1 9/16
1/4-20 7 1 3/4-12 1 43/64
1/4-28 3 2-4 1/2 1 25/32
5/16-18 F 2-12 1 59/64
5/16-24 I 2 1/4-4 1/2 2 1/32
3/8-16 O 2 1/2-4 2 1/4
3/8-24 Q 2 3/4-4 2 1/2
7/16-14 U 3-4 2 3/4
7/16-20 25/64
Tap Size Drill Size
Decimal
Equivalent
Nearest
Fraction
3x.50 #39 0.0995 3/32
3x.60 3/32 0.0937 3/32
4x.70 #30 0.1285 1/8
4x.75 1/8 0.125 1/8
5x.80 #19 0.166 11/64
5x.90 #20 0.161 5/32
6x1.00 #9 0.196 13/64
7x1.00 16/64 0.234 15/64
8x1.00 J 0.277 9/32
8x1.25 17/64 0.265 17/64
9x1.00 5/16 0.3125 5/16
9x1.25 5/16 0.3125 5/16
10x1.25 11/32 0.3437 11/32
10x1.50 R 0.339 11/32
11x1.50 3/8 0.375 3/8
12x1.50 13/32 0.406 13/32
12x1.75 13/32 0.406 13/32
