Monitors and Cameras

Connecting Monitors

The following table shows how you can connect monitors to a Polycom HDX

system. The monitor connected to video output 1 displays the Polycom HDX

system user interface.

For Monitor 1 and Monitor 2, the system provides both dual BNC connectors

and a DVI-I connector. Only one at a time is active. If both outputs are

connected to monitors, only the DVI-I connector is active.

Video Output Number Connector Output Formats

1 BNC (two) S-Video, Composite

DVI-I VGA, DVI, HDMI, Component

2 BNC (two) S-Video, Composite

DVI-I VGA, DVI, HDMI, Component

3 (VCR/DVD Player) BNC (two) S-Video, Composite

4 (Content) DVI-I VGA, DVI, HDMI, Component
