Polycom HDX Series Administrator's Guide

Monitors and Cameras
3 - 11
Connecting Cameras
Polycom HDX systems provide inputs for multiple PTZ cameras. You can use
the RS-232 serial port on the Polycom HDX system to control non-Polycom
cameras or cameras not connected to input 1 or 2.
If you connect a supported PTZ camera, the system detects the camera type
and sets the appropriate configuration.
Refer to your system’s setup sheet for connection details. Refer to the release
notes for a list of supported PTZ cameras.
The following table shows how you can connect video sources to a Polycom
HDX system.
When connecting a Polycom Eagle Eye camera to video input 2, use only the
approved power supply from Polycom (part number 1465-52621-036). Do not
exceed 12 Volts at 3 Amps.
Video Input Number Connector
Acceptable
Input
Audio
Association Power Control
1 HDCI Composite,
S-Video,
Component
None Provided Camera PTZ,
IR Input
2 HDCI Composite,
S-Video,
Component
None None Camera PTZ
3 (VCR/DVD Player) BNC (three) Composite,
S-Video,
Component
Audio Input 3 None None
4 (Content) DVI-I VGA, DVI Audio Input 4 None None
5 (Content) DVI-I VGA, DVI None None None

Polycom HDX Series Specifications

General

Network Protocols	H.323, SIP
Video Resolution	1080p (depending on model)
Audio Technology	Polycom StereoSurround
Content Sharing	People+Content
Microphone	Integrated or external
Video Standards	H.264, H.263
Audio Standards	G.711, G.722, G.722.1, G.728
Data Standards	H.239
Network Interface	10/100/1000 Ethernet
Video Inputs	HDMI, DVI-I
Video Outputs	HDMI, DVI-I
Audio Inputs	HDMI, RCA
Audio Outputs	RCA
Power Consumption	Varies by model
Operating Temperature	0°C to 40°C (32°F to 104°F)
Humidity	10% to 90% non-condensing
