Reference Number Feature
4 USB 3.0 host port
If you plug a dongle for a wireless pointing device into the USB 2.0 port and connect a
USB flash drive to the USB 3.0 port, the wireless pointing device may not function
properly.
5 USB 2.0 host port
If you plug a dongle for a wireless pointing device into the USB 2.0 port and connect a
USB flash drive to the USB 3.0 port, the wireless pointing device may not function
properly.
6 10/100/1000 Ethernet port
The device ships with this Ethernet port covered. This port is reserved for future use.
7 10/100/1000 Ethernet port powered with PoE+ PD
This port supports IEEE 1588 for time synchronization with devices in a room.
8 2.0 mm jack for optional external 54 V DC power adapter
System Indicator Lights
The LED on the front of the Pano device system provides the following information.
Indicator Light System Status
Off or blinking red light System is disconnected, cannot initialize, or has encountered a severe
malfunction
Steady white light System is initializing
Steady blue light System is running
Alternating blue and amber lights System is in software update or factory restore mode
Powering On and Off
The system turns on when you plug it into a power source. The system doesn’t have a power button, so
you must unplug the power cable to turn it off.
You can power the device with the following:
▪ Power over Ethernet+ (PoE+) IEEE 802.3at Type 2 (Link Layer Discovery Protocol [LLDP]
negotiation is supported for switches that require it)
▪ 2.0 mm power adapter
Remember the following when powering the Pano device:
Getting Started
Polycom, Inc. 6
