Polycom SoundPoint IP 550 User Manual

User Guide for the SoundPoint IP 550/560 Phone
3 - 4
To place a call using the headset:
>> Do one of the following:
— With the optional headset connected, press or the
NewCall soft key to obtain dial tone.
Press .
Dial the desired number using the dial pad.
— With the optional headset connected, dial the desired number using
the dial pad.
Press .
Answering Calls
When you are not in another call, you can answer a call in three ways:
• Using the handset
• Using the speakerphone
• Using the headset
The steps for answering an incoming call when you are in another call are
different if your phone is configured for:
• A single Line Key per line
Note
To permanently enable your headset, refer to Enabling the Headset Memory Mode
on page 2-6.

Polycom SoundPoint IP 550 Specifications

General

Full duplex	Yes
Camera included	No
Frequency range	150 - 7000 Hz
Base station keys	26 + 4
Channels quantity	2 channels
Dimensions (WxDxH)	265 x 150 x 190 mm
Networking features	DHCP/Static IP
Ethernet LAN (RJ-45) ports	2
Supported network protocols	FTP, TFTP, HTTP, HTTPS
Supported data transfer rates	10/100 Mbit/s
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	20 - 85 %
Power requirements	48V DC
Volume control	Digital
Voice codecs	G.722
Backlight color	-
Display resolution	320 x 160 pixels
Safety	UL/C-UL; CE Mark-1; EN 60950-1; IEC 60950-1; AS/NZS 60950
Certification	- FCC Part 15 (CFR 47) Class B - ICES-003 Class B - EN55022 Class B - CISPR22 Class B - AS/NZS CISPR 22 Class B - VCCI Class B - EN55024 - EN61000-3-2; EN61000-3-3 - ROHS - Anatel - GOST - C-tick - CCC
Compliance industry standards	IEEE 802.3af; IEEE 802.1p;IEEE 1329; RFC 1889

Weight and Dimensions

Weight	2045 g
