Using the Basic Features of Your Phone
3 - 19
Forwarding Calls
You can configure your phone so that all incoming calls are forwarded to
another party (refer to Static Forwarding). You can also forward calls while
your phone rings (refer to Dynamic Forwarding).
All incoming calls can be forwarded to another party while Do Not Disturb is
enabled on your phone. For more information, contact your system
administrator.
Static Forwarding
To forward all incoming calls to another party:
1. From the idle display, press the Forward soft key.
2. (Optional.) If multiple lines are configured on your phone, select the line
to forward from the list using and .
3. Using and , select the forwarding type you want to change,
and then press the Select soft key. The options are:
Always—To forward all incoming calls
—No Answer—To forward unanswered incoming calls
—Busy—To forward calls that arrive when you are already in a call
4. Depending on your selection:
Note
Call Forwarding is not available on shared lines.
This feature is local to the phone, and may be overridden by call server settings.
For more information, contact your system administrator.

Table of Contents

Other manuals for Polycom SoundPoint IP 550

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Polycom SoundPoint IP 550 and is the answer not in the manual?

Polycom SoundPoint IP 550 Specifications

General IconGeneral
Full duplexYes
Camera includedNo
Frequency range150 - 7000 Hz
Base station keys26 + 4
Channels quantity2 channels
Dimensions (WxDxH)265 x 150 x 190 mm
Networking featuresDHCP/Static IP
Ethernet LAN (RJ-45) ports2
Supported network protocolsFTP, TFTP, HTTP, HTTPS
Supported data transfer rates10/100 Mbit/s
Product colorGray
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)10 - 40 °C
Operating relative humidity (H-H)20 - 85 %
Power requirements48V DC
Volume controlDigital
Voice codecsG.722
Backlight color-
Display resolution320 x 160 pixels
SafetyUL/C-UL; CE Mark-1; EN 60950-1; IEC 60950-1; AS/NZS 60950
Certification- FCC Part 15 (CFR 47) Class B - ICES-003 Class B - EN55022 Class B - CISPR22 Class B - AS/NZS CISPR 22 Class B - VCCI Class B - EN55024 - EN61000-3-2; EN61000-3-3 - ROHS - Anatel - GOST - C-tick - CCC
Compliance industry standardsIEEE 802.3af; IEEE 802.1p;IEEE 1329; RFC 1889
Weight and Dimensions IconWeight and Dimensions
Weight2045 g
