Using the Basic Features of Your Phone
3 - 23
Assigning Speed Dial Keys
You can associate contacts with Line Keys for single touch dialing of
frequently used numbers. Speed Dial entries are consecutively placed next to
assigned Line Keys on the phone. When a new entry is added to the Contact
Directory, it is automatically assigned the next available speed dial index and
the next available line key.
In the figure below, the phone has one line key, and three available speed dial
keys (assigned to Byron, Lauren, and Andrew). To dial Byron, Lauren, or
Andrew, press the associated line key.
To add or edit a speed dial index for an existing contact:
1. Press .
2. Select Contact Directory.
3. Use and to highlight the contact.
You can also use the * key to page up and the # key to page down.
4. Press the Edit soft key.
Note
To quickly access a list of speed dial index numbers, press the Up Arrow key from
the idle screen. To speed dial a contact, press the Up Arrow key followed by the
contact’s speed dial index. For example, if Joan’s speed dial index is 55, pressing
the Up Arrow key followed by 55 will place a call to Joan.

Table of Contents

Other manuals for Polycom SoundPoint IP 550

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Polycom SoundPoint IP 550 and is the answer not in the manual?

Polycom SoundPoint IP 550 Specifications

General IconGeneral
Full duplexYes
Camera includedNo
Frequency range150 - 7000 Hz
Base station keys26 + 4
Channels quantity2 channels
Dimensions (WxDxH)265 x 150 x 190 mm
Networking featuresDHCP/Static IP
Ethernet LAN (RJ-45) ports2
Supported network protocolsFTP, TFTP, HTTP, HTTPS
Supported data transfer rates10/100 Mbit/s
Product colorGray
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)10 - 40 °C
Operating relative humidity (H-H)20 - 85 %
Power requirements48V DC
Volume controlDigital
Voice codecsG.722
Backlight color-
Display resolution320 x 160 pixels
SafetyUL/C-UL; CE Mark-1; EN 60950-1; IEC 60950-1; AS/NZS 60950
Certification- FCC Part 15 (CFR 47) Class B - ICES-003 Class B - EN55022 Class B - CISPR22 Class B - AS/NZS CISPR 22 Class B - VCCI Class B - EN55024 - EN61000-3-2; EN61000-3-3 - ROHS - Anatel - GOST - C-tick - CCC
Compliance industry standardsIEEE 802.3af; IEEE 802.1p;IEEE 1329; RFC 1889
Weight and Dimensions IconWeight and Dimensions
Weight2045 g
