This selection brings up the “Sites” screen. Within the “Sites” screen, select the name of the site to
configure. The “Edit Site” screen will then appear. Scroll down to the “SIP Proxy” parameters (Figure
8).
Figure 8 – Site Screen SIP Proxies
The “Virtual IP Address” parameter is a new configuration parameter with ShoreTel 8. This “Virtual IP
Address” is an IP address that can be moved to a different switch during a failure. For each site that
supports SIP extensions, one “Virtual IP Address” is defined that will act as the SIP Proxy for the site.
This IP address must be unique and static.
The ShoreTel server will assign this “Virtual IP Address” to the ShoreGear that is configured as SIP
proxy for the site. Two ShoreGear switches can be configured as SIP proxy servers for redundancy and
reliability purposes. If the primary proxy server goes down, the other proxy switch will take over the
“Virtual IP Address.” Due to this “Virtual IP Address” mechanism, SIP phones will not know if the
proxy switch goes off-line.
Note: If you choose not to define a “Virtual IP Address,” you can only define one proxy switch, and
there will be no redundancy or failover capabilities. The switches available in the “Proxy Switch 1 / 2”
will only be shown if proxy resources have been enabled on the switch.
