Hardware Configuration
RUBY-9715VG2AR User’s Manual 2-3
J24 3rd pairs of USB Connector
J26 4th pairs of USB Connector
J27 3-pin Fan Connector
J29 ~ J32 SATA Connector
J33, J34, J41 Bettery Connector
J35 SMBus Connector
J36 IrDA Connector
J37 4-pin Fan Connector
J38 General Purpose I/O Connector
J39 IDE Connector
J42 FDC Interface Connector
J43 ATX Power Connector
Note:
Power Button : J19-pin 9 and J19-pin 11
Reset Button : J19-pin 17 and J19-pin 19
Power LED : J19-pin 2 and J19-pin 6
Speaker :J19-pin 14 and J19-pin 20
HDD LED : J19-pin 1 and J19-pin 3
Pin Assignments of Connectors
J1 : On-board VGA CRT Connector
PIN No. Signal Description
1 Red
2 Green
3 Blue
4 Monitor ID0 (MONID0) (5V I/F)
5 Ground
6 Ground
7 Ground
8 Ground
9 +5V
10 Ground
11 Monitor ID1 (MONID1) (5V I/F)
12 VGA DDC Data (5V I/F)
13 Horizontal Sync. (HSYNC) (5V I/F)
14 Vertical Sync. (VSYNC) (5V I/F)
15 VGA DDC Clock (5V I/F)
