Portwell RUBY-9715VG2AR - Integrated Peripherals

BIOS Setup Information
RUBY-9715VG2AR User’s Manual 4-15
On-Chip Frame Buffer Size
The choice: 1MB, 8MB.
DVMT Mode
The choice: DVMT, FIXED and BOTH.
DVMT /FIXED Memory Size
The choice: 64MB, 128MB.
4.7 Integrated Peripherals
Phoenix- AwardBIOS CMOS Setup Utility
Integrated Peripherals
Item Help
f OnChip IDE Device [Press Enter]
f Onboard Device [Press Enter]
f Super IO Device [Press Enter]
Menu Level f
↑↓→←: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Phoenix- AwardBIOS CMOS Setup Utility
OnChip IDE Device
Item Help
IDE HDD Block Mode [Enabled]
IDE DMA transfer access [Enabled]
On-Chip Primary PCI IDE [Enabled]
IDE Primary Master PIO [Auto]
IDE Primary Slave PIO [Auto]
IDE Primary Master UDMA [Auto]
IDE Primary Slave UDMA [Auto]
*** On-Chip Serial ATA Setting ***
X SATA Mode IDE
On-Chip Serial ATA [Enhanced]
X SATA PORT Speed Settings Disabled
X PATA IDE Mode Primary
SATA Port P1, P3 is Secondary
Menu Level f
If
y
our IDE hard drive
supports block mode
select Enabled for
automatic detection of
the optimal number of
block read/writes per
sector the drive can
support.
↑↓→←: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
