Portwell RUBY-9715VG2AR - Connector Allocation

Hardware Configuration
RUBY-9715VG2AR User’s Manual 2-2
JP2 : LAN ENABLE/DISABLE
JP2 Function
1-2 Short ENABLE by BIOS Ì
2-3 Short DISABLE
JP8 : COM1(J2) Interface Selection
JP8 Function
5-6,9-11,10-12,15-17,16-18 Short RS-232 Ì
3-4,7-9,8-10,13-15,14-16,21-22 Short RS-422
1-2,7-9,8-10,19-20 Short RS-485
JP9 : CMOS Clear
JP9 Function
1-2 Short Normal Operation Ì
2-3 Short Clear CMOS Contents
2.2 Connector Allocation
I/O peripheral devices are connected to the interface connectors on this Industrial
Mainboard.
Connector Function List
Connector Description Remark
J1 On-board VGA CRT Connector
J2 COM1 Serial Port 1 Connector
J3 Audio Jack
J4 Parallel Port Connector
J5 PS/2 Keyboard/Mouse Connector
J6 Primary USBx2 + LAN Connector
J7 Secondary USBx2 + LAN Connector
J8 Audio MIC/Line-in/Line-out Connector
J9 Audio CD-in Connector
J10 ATX8, 12V POWER CON.
J11 ~ J16 PCI Connector
J17 COM2 Serial Port 2 Connector
J18 PCI-Express x 16 Connector
J19 Front Panel Connector
J22 External Wake On Ring Connector
J23 4-pin Fan Connector
