Portwell RUBY-9715VG2AR - Page 19

Hardware Configuration
RUBY-9715VG2AR User’s Manual 2-9
A43 PAR B43 VCC3
A44 AD15 B44 C/BE#1
A45 VCC3 B45 AD14
A46 AD13 B46 Ground
A47 AD11 B47 AD12
A48 GND B48 AD10
A49 AD9 B49 GND
A50 KEY B50 KEY
A51 KEY B51 KEY
A52 C/BE#0 B52 AD8
A53 VCC3 B53 AD7
A54 AD6 B54 VCC3
A55 AD4 B55 AD5
A56 Ground B56 AD3
A57 AD2 B57 GND
A58 AD0 B58 AD1
A59 VCC B59 VCC
A60 4.7K Pull-High VCC B60 4.7K Pull-High VCC
A61 VCC B61 VCC
A62 VCC B62 VCC
J13 : PCI Connector
PIN No. Signal Description PIN No. Signal Description
A01 TRST# (Pull-Low) B01 -12V
A02 12 V B02 4.7K Pull-Low
A03 PTMS (2.7K Pull-high 5V) B03 GND
A04 PTDI (2.7K Pull-high 5V) B04 N/C
A05 VCC B05 VCC
A06 PIRQ#G B06 VCC
A07 PIRQ#D B07 PIRQ#B
A08 VCC B08 PIRQ#F
A09 N/C B09 N/C
A10 VCC B10 N/C
A11 N/C B11 N/C
A12 GND B12 GND
A13 GND B13 GND
A14 N/C B14 NC
A15 PCIRST# B15 GND
A16 VCC B16 PCI Clock
A17 PGNT#3 B17 GND
A18 GND B18 PREQ#3
A19 PME# B19 VCC
A20 AD30 B20 AD31
A21 VCC3 B21 AD29
