BIOS Setup Information
RUBY-9715VG2AR User’s Manual 4-6
Cylinder Min = 0
Max = 65535
Set the number of cylinders for this
hard disk.
Head Min = 0
Max = 255
Set the number of read/write heads
Precomp Min = 0
Max = 65535
**** Warning: Setting a value of 65535
means no hard disk
Landing zone Min = 0
Max = 65535
****
Sector Min = 0
Max = 255
Number of sectors per track
Phoenix- AwardBIOS CMOS Setup Utility
IDE Channel 2 Slave
Item Help
IDE HDD Auto-Detection [Press Enter]
IDE Channel 1 Master [Auto]
Access Mode [Auto]
Capacity 80GB
Cylinder 38309
Head 16
Precomp 0
Landing Zone 38308
Sector 255
Menu Level f
To atuo-detect the HDD’s
size, head … on this
channel
↑↓→←: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
 Menu Selections
Item Options Description
IDE HDD Auto-
detection
Press Enter Press Enter to auto-detect the HDD on this
channel. If detection is successful, it fills
the remaining fields on this menu.
IDE Channel 2
Master
None
Auto
Selecting ‘manual’ lets you set the
remaining fields on this screen. Selects the
type of fixed disk. "User Type" will let you
select the number of cylinders, heads, etc.
Note: PRECOMP=65535 means NONE!
Access Mode Large, Auto Choose the access mode for this hard disk
Capacity Auto Display your
disk drive size
Disk drive capacit
y
(Approximated). Note
that this size is usually slightly greater than
the size of a formatted disk given by a disk-
checking program.
