BIOS Setup Information
RUBY-9715VG2AR User’s Manual 4-17
On-Chip Serial ATA
Disabled Disabled SATA Controller.
Auto Auto arrange by BIOS.
Combined Mode
PATA and SATA are combined. Max. Of 2 IDE drives in each
channel.
Enhanced Mode
Enable both SATA and PATA. Max. Of 6 IDE drives are
Supported.
SATA Only SATA is operating in legacy mode.
Phoenix- AwardBIOS CMOS Setup Utility
Onboard Device
Item Help
USB Controller [Enabled]
USB 2.0 Controller [Enabled]
USB Keyboard Support [Enabled]
USB Mouse Support [Disabled]
Onboard AC97 Control [Enabled]
Onboard LAN1 Control [Enabled]
Onboard LAN2Control [Enabled]
Menu Level f
↑↓→←: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
USB Controller
This item allows you to enable/disable USB (Universal Serial Bus) function.
The choice: Enabled, Disabled.
USB 2.0 Controller
This entry is for disable/enable EHCI controller only. This BIOS itself may/may
not have high speed USB support built in, the support will be automatically turn on
when high speed device were attached.
The choice: Enabled, Disabled.
USB Keyboard Support
This item allows you to enable USB keyboard function under POST, BIOS setup
menu, DOS, or Windows-NT with no USB driver loaded.
The choice: Enabled, Disabled.
