BIOS Setup Information
RUBY-9715VG2AR User’s Manual 4-20
Parallel Port Mode
There are four different modes for the onboard parallel port :
SPP
Switch to SPP mode
EPP
Switch to EPP mode
ECP
Switch to ECP mode
ECP + EPP
Switch to ECP + EPP mode
Normal
Switch to Normal mode
EPP Mode Select
Select different version of EPP mode.
The choice: EPP1.7, EPP1.9.
ECP Mode Use DMA
Select a proper DMA channel for ECP mode.
The choice: 1, 3.
Watch Dog Timer Select
This BIOS testing option is able to reset the system according to the selected table.
The choice: Disabled, 10 Sec, 20 Sec, 30 Sec, 40 Sec, 1 Min, 2 Min, and 4 Min.
