System Overview
RUBY-9715VG2AR User’s Manual 1-4
PS/2 Mouse and Keyboard Interface
Dual Mini-DIN connector for external PS/2 keyboard and mouse
Audio
- Connector and header of Line-in/Line-out/MIC for external and internal usage
Auxiliary I/O Interfaces
System power on/off switch, reset switch, external speaker, Keyboard lock and
HDD active indication, etc
Real Time Clock/Calendar (RTC)
Support Y2K Real Time Clock/Calendar with battery backup for 7-year data
retention
Watchdog Timer
- Support WDT function through software programming for enable/disable and
interval setting
- Generate system reset
On-board VGA
- GMCH integrated GMA950 graphics controller with 24-bit 400MHz RAMDAC
- Up to 2048 x 1536 at 75Hz refresh (QXGA)
- Dynamic Video Memory Technology (DVMT) support up to 224MB
- Two multiplexed SDVO port interfaces with 200MHz pixel clocks using an
ADD2/ADD2+ card
- With Advanced Digital Display (ADD2/ADD2+) cards, support for TV-
out/TV-in and DVI digital display connections
- Supports flat panels up to 2048 x 1536 at 60Hz or digital CRT/HDTV at 1920 x
1080 at 85Hz (with ADD2/ADD2+)
On-board Ethernet LAN
Dual Gigabit (10/100/1000 Mbits/sec) LAN port using the Intel 82573L Gigabit
Ethernet Controller
High Driving GPIO
Support 8 programmable high driving GPIO
Cooling Fans
- Support two 4-pin headers for Processor, System fans
- Support one 3-pin header for System fan
System Monitoring Feature
Monitor CPU temperature, system temperature and major power sources, etc
Outline Dimension (L X W):
312.8mm (12.3”) X 243.8mm (9.6”)
