Posch SplitMaster 30 - The most Important Components of the Machine

The cylinder stroke can be adjusted to shorter logs.
The "Autospeed" function ensures a very high splitting speed.
The splitter is driven hydraulically; the hydraulic system is either driven by an electric motor,
a PTO shaft or by a diesel engine.
The machine is operated via a two-hand safety controller.
As soon as the control levers of the safety circuit have been pulled back simultaneously,
the pressure plate is advanced.
As soon as you release one of the two control levers, the pressure plate halts. If you push
both control levers away from you, the pressure plate returns to its starting position.
A lifting device lifts the log up onto the support.
The pressure plate presses the log against the splitting knife when working and splits it.
The height of the splitting knife can be adjusted hydraulically, enabling it to be adapted to
any log diameter.
The most important components of the machine
5
1
2
3
4
6
7
8
9
11
12
1010
1 Splitting blade 7 Oil filter
2 Tool guide 8 Oil drain screw
3 Pusher 9 Control lever for lifting device and
splitting blade
4 Three-point hitch 10 Control lever for splitter
5 Identification plate 11 Lifting device
6 Cylinder 12 Timber support
3.3
