Hydraulic lines
After the first hour of operation, check that all hydraulic connections are secure and are not
leaking.
Check that all hydraulic connections are secure and are not leaking after every further
100 hours of operation.
▪ Damaged hydraulic lines must be replaced immediately.
Tool guide
The tool guide must always be well greased.
Two-hand controller
Check the joints of the two-hand controller to make sure they move easily and lubricate if
necessary.
Check that the rocker moves freely.
Oil level
To check the oil level place the machine on an even surface.
Check the oil level with the pusher retracted.
Hydraulic oil level
When the oil sight glass is filled above halfway, the oil level is at its maximum.
When the oil level is towards the bottom of the oil sight glass, the oil level its at its minimum.
1 Ventilation screw 3 Oil drain screw
2 Oil sight glass
If this is the case, the hydraulic oil must be topped up immediately.
▪ See: Changing the hydraulic oil [➙ 33]
The oil filter only needs to be checked when the oil is changed.
8.4
8.5
8.6
8.7
8.7.1
Checks
32
