▪ Fully lower the lifting device.
▪ Place the log on the lifting device and raise it.
– The log automatically rolls into the splitting trough.
without second split:
▪ Fully lower the lifting device.
Align the splitting blade.
▪ If you wish to split the log into two billets, the splitting blade must be lowered as far as
it will go.
▪ If you wish to split the log into four billets, the height of the splitting blade must be
adjusted so that the blade is aligned with the centre of the log.
▪
Make sure that the splitting blade is positioned centrally relative to the log; failure
to do so may result in damage to the splitting blade.
with second splitting operation (only with "Easy" splitting knife):
1
2
A
A
B
B
C
C
1.
2.
3.
1
"Easy" splitting knife 2 Lumber pick
Operation
