VISUALIZATION AND STATUS PARAMETERS. GROUP G0
19
3.6. Parameters SV.6 – Registers
This group includes several registers of general information about the drive use. Therefore, we can
visualize a total and partial counter for running time (RUN).
Screen
Units
Description
TOT= d h
Days and Hours
It shows the total time during which the drive is running (RUN).
PAR= d h
Days and Hours
It shows the partial time during which the drive is running (RUN).
CLEAR PARTIAL=N
-
It allows resetting the counter of partial time for running status (RUN).
MOTOR ENERGY
kWh/MWh/GWh
Shows the drive energy consumption in motor mode operation.
REGEN. ENERGY
kWh/MWh/GWh
Shows the regenerated energy in regeneration mode operation.
RSET PRTL ENRG
Y/N
The user is able to reset the partial energy counters.
3.7. Parameters SV.7 – Rectifier
This group includes several registers of general information about the rectifier bridge.
Screen
Units
Description
Pow in
kW
It shows the input power.
IR & IS & IT
A
It shows the currents per phase.
R. Phi Cos
-
It shows the input cos PHI or Displacement Power Factor (DPF).
Rec T IGBT
ºC
It shows the maximum temperature of rectifier‟s IGBT.
PLL frq
Hz
It shows the internal PLL frequency.
