Power Electronics SD700 User Manual

SD700FR SERIES
POWER ELECTRONICS
50
DESCRIPTION OF PROGRAMMING PARAMETERS
4.17. Group 17 – G17: Brake
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
1 T DC BRAKE=OFF
DC BRAKING TIME
G17.1 / Time for
DC brake
activation
OFF=0.0 to
99s
Allows setting of the time for which the DC brake will be activated.
YES
2 DC CURR=0%
DC CURRENT LEVEL
G17.2 / Current
applied to the
brake
0 – 100%
Allows setting of the current level applied during braking. The proper current value
must be set to brake the load inertia correctly. If this value is too much low the
load will not be stopped in time. If the value is too high the power components of
the drive will be stressed.
YES
3 DC VOLTS=0.0%
DC BR VOLT LEVEL
G17.3 / Voltage
applied to the
brake
0.0 – 25%
Allows setting of the continuous DC voltage level applied during braking. The
proper voltage value must be set to brake the load inertia correctly. If this value is
too much low load will not be stopped in time. Otherwise, if the value is too high
the power components of the drive will be stressed.
YES
4 I HEATING=OFF
Idc HEATING
G17.4 / Non
condensing
heating current
OFF=0.0 to
30%
Set a suitable value to avoid humidity or condensation forming in the motor.
Note: Modify this parameter only if necessary.
CAUTION: Although the motor is not running there is dangerous voltage.
Run Led will be lit during this process. Be careful to avoid property damage and
personal injuries.
YES
4.18. Group 18 – G18: Encoder
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
1 PULSES=1024
G18.1 / Pulses
per revolution of
the encoder
200 to 8191
Set the encoder installed in the motor pulses per revolution
SI
2 TYPE=DIFF
G18.2 / Encoder
Type
DIFF
SING
Select the type of encoder installed in the motor
OPT.
FUNCTION
DIFF
Differential output encoder
SING
Single-ended output encoder
NO
3 ENCOD FILTER=N
G18.3/ Encoder
filter selection
YES
NO
Filters the encoder signal
NO
