Power Electronics SD700 User Manual

SD700FR SERIES
POWER ELECTRONICS
56
DESCRIPTION OF PROGRAMMING PARAMETERS
4.21. Group 21 – G21: Networks
This parameter group is used to configure the drive when it should operate in Ethernet network.
Note: This parameter group and its corresponding subgroups will be only available when the Ethernet board is
connected to the drive.
4.21.1. Subgroup 21.1 – S21.1: ETHERNET
This parameter subgroup is used to configure the identification parameters of the drive in the
Ethernet network (IP, Subnet Mask, Gateway), and the MAC address.
Parameter /
Default Value
Name / Description
Range
Function
Set on
RUN
1 AUTOMATIC IP=Y
G21.1.1 / To enable
automatic assignation
of parameters
N
Y
It allows the possibility of assigning the parameters automatically.
OPT.
FUNCTION
N=NO
The drive will take IP, Subnet Mask and Gateway
addresses set by user from subgroup S21.1.
Y=YES
The drive request and receives the parameters of
the IP, Subnet Mask and Gateway addresses
from the Network Server. To achieve this, it is
used DHCP protocol.
YES
Ixxx.yyy.zzz.hhh
Present IP address of
the drive
-
It shows the IP address assigned to the drive automatically or set by the user from
the parameters G21.1.2, G21.1.3, G21.1.4 and G21.1.5.
-
Sxxx.yyy.zzz.hhh
Present Subnet Mask
of the drive
-
It shows the Subnet Mask address assigned to the drive automatically or set by
the user from parameters G21.1.6, G21.1.7, G21.1.8 and G21.1.9.
-
Gxxx.yyy.zzz.hhh
Present Gateway of
the drive
-
It shows de Gateway address assigned to the drive automatically or set by the
user from parameters G21.1.10, G21.1.11, G21.1.12 and G21.1.13.
-
2 IP MANU. A=192
[6]
G21.1.2 /
IP address (A)
0 to 255
Setting of the IP address assigned to the equipment in the local network of the
user. This address must be provided by the network administrator of the own user.
The format of the IP address is the following one: A.B.C.D.
Therefore, the setting of this address is realized by introducing a value in each
parameter that configures the complete address, this is, by assigning a value to
each one of the 4 parameters (from parameter G21.1.2 to the parameter G21.1.5).
YES
3 IP MANU. B=168
[6]
G21.1.3 /
IP address (B)
0 to 255
YES
4 IP MANU. C=1
[6]
G21.1.4 /
IP address (C)
0 to 255
YES
5 IP MANU. D=143
[6]
G21.1.5 /
IP address (D)
0 to 255
YES
6 SUBNET A=255
[6]
G21.1.6 /
Subnet Mask address
(A)
0 to 255
Setting of the Subnet Mask address of the local network of the user. This address
must be provided by the network administrator of the own user.
The format of the Subnet Mask address is the following one: A.B.C.D.
Therefore, the setting of this address is realized by introducing a value in each
parameter that configures the complete address, this is, by assigning a value to
each one of the 4 parameters (from parameter G21.1.6 to the parameter G21.1.9).
YES
7 SUBNET B=255
[6]
G21.1.7 /
Subnet Mask address
(B)
0 to 255
YES
8 SUBNET C=255
[6]
G21.1.8 /
Subnet Mask address
(C)
0 to 255
YES
9 SUBNET D=0
[6]
G21.1.9 /
Subnet Mask address
(D)
0 to 255
YES
10 GATEWAY A=0[6]
G21.1.10 / Gateway
address (A)
0 to 255
Setting of the Gateway address of the local network of the user. This address is
needed to the drive access to an external network. This address must be provided
by the network administrator of the own user.
The format of the Gateway address is the following one: A.B.C.D.
Therefore, the setting of this address is realized by introducing a value in each
parameter that configures the complete address, this is, by assigning a value to
each one of the 4 parameters (from parameter G21.1.10 to the parameter
G21.1.13).
YES
11 GATEWAY B=0[6]
G21.1.11 / Gateway
address (B)
0 to 255
YES
12 GATEWAY C=0[6]
G21.1.12 / Gateway
address (C)
0 to 255
YES
13 GATEWAY D=0[6]
G21.1.13 / Gateway
address (D)
0 to 255
YES
14 MAC A=0
G21.1.14 /
MAC address (A)
0 to 255
Setting of the MAC address. This address is unique and exclusive, and is
associated to the LAN board / drive. It must be provided by Power Electronics.
The format of the MAC address is the following one: A.B.C.D.E.F.
This address should be unique and is assigned by the manufacturer. In case of
Power Electronics:
MAC A = 0
MAC B = 80
MAC C = 194
MAC D = 114
MAC E = X (any value from 0 to 255)
MAC F = Y (any value from 0 to 255)
Note: Check this during the trial run. If any part of the address does not match
with the values above indicated, contact with Technical Department from Power
Electronics which provides you with a MAC address and indicates you how to
introduce it, in order to assure the correct operation.
YES
15 MAC B=80
G21.1.15 /
MAC address (B)
0 to 255
YES
16 MAC C=194
G21.1.16 /
MAC address (C)
0 to 255
YES
17 MAC D=114
G21.1.17 /
MAC address (D)
0 to 255
YES
18 MAC E=X
G21.1.18 /
MAC address (E)
0 to 255
YES
19 MAC F=Y
G21.1.19 /
MAC address (F)
0 to 255
YES
[6]
This parameters will be only available if 'G21.1.1 AUTOMATIC IP = N‟.
