DESCRIPTION OF PROGRAMMING PARAMETERS
4.22. Group 22 – G22: Rectifier
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
1 Vdc REF= (*)
Vdc reference
G22.1 / Vdc
reference
(*)
This parameter allows setting the DC bus voltage. A high Vdc could cause greater
power losses and a high output dV/dt value.
It is recommended to set it following the next equation:
VdcREF=Vin*√2*1.1
Note: (*)
Drive rated Voltage (V)
Range (Vdc)
Default Value (Vdc)
380Vac-480Vac
500Vdc – 825Vdc
600Vdc
525Vac
650Vdc – 900Vdc
800Vdc
690Vac
850Vdc – 1150Vdc
1050Vdc
YES
2 Cos phi=1
CosPHI reference
G22.2 / CosPHI
reference
0.9 – 1
This parameter allows setting the displacement power factor (cos PHI).
YES
3 CAP/IND=CAP
CosPHI CHAR
G22.3 / CosPHI
characteristics
CAP – IND
This parameter allows the selection between capacitive or inductive cos PHI.
NO
4 FREQ RE=2800
Rect.frequency
G22.4 / Rect.
frequency
1500Hz –
8000Hz
This parameter allows setting the rectifier bridge IGBT switching frequency. It is
recommended to keep factory settings.
YES
5 TIME OFF=0.0
Delay OFF Rect.
G22.5 / Delay
OFF Rect.
0.0s – 60.0s
OFF
This parameter permits to delay the rectifier bridge switching off. This parameter
increases the dynamic response in applications with continuous start and stop
commands (cranes, precision conveyors, etc.)
NO
8 AD K=N
Active Damping K.
G22.8 / Active
Damping K
N – Y
This parameter enables the active damping algorithm to avoid the LCL filter
resonance.
NO
9 AD HPF=500
AD Filter
G22.9 / AD Filter
50Hz –
1000Hz
Allows setting the high pass filter‟s frequency of the active damping algorithm.
NO
4.22.1. Subgroup 22.10 – S22.10: PID configuration
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
1 Kp PLL=10.0
PID Kp PLL
G22.10.1 / PID
Kp PLL
0.0 – 100.0
Allows setting the PID proportional gain value of the PLL. (Rectifier bridge)
YES
2 Ki PLL=15.0
PID Ki PLL
G22.10.2 / PID
Ki PLL
0.0 – 100.0
Allows setting the PID integral gain value of the PLL. (Rectifier bridge)
YES
3 Kp Vdc=10.0
PID Kp Vdc
G22.10.3 / PID
Kp Vdc
0.0 – 100.0
Allows setting the PID proportional gain value of the bus voltage loop control.
(Rectifier bridge)
YES
4 Ki Vdc=3.5
PID Ki Vdc
G22.10.4 / PID
Ki Vdc
0.0 – 100.0
Allows setting the PID integral gain value of the bus voltage loop control. (Rectifier
bridge)
YES
5 Kp I=10.0
PID Kp I
G22.10.5 / PID
Kp I
0.0 – 100.0
Allows setting the PID proportional gain value of the current loop control. (Rectifier
bridge)
YES
8 Ki I=10.0
PID Ki I
G22.10.6 / PID
Ki I
0.0 – 100.0
Allows setting the PID integral gain value of the current loop control. (Rectifier
bridge)
YES
4.22.2. Subgroup 22.11 – S22.11: Protections
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
5 I lim REC=1.5xIn
G22.11.5 /
Current lim
Rectifier
1xIn – 2xIn
This parameter allows stopping the drive by generating “R21 I LIMIT IN” fault
when the input current value is above the threshold set in this parameter.
YES
6 T I Limit= OFF
G22.11.6 / Time
Delay Current
Limit Rect
0 to 60s
OFF
This parameter allows setting the delay before the fault “R21 I LIMIT IN”.
YES
7 I Imb=30.0%
G22.11.7 /
Current
Imbalance
OFF
00.0%-
50.0%
This parameter allows stopping the drive by generating “R19 I IMB IN” fault when
the inverse input current value is above the threshold set in this parameter.
YES
8 I Gnd=30.0%
G22.11.8/
Ground current
fault
OFF
00.0%-
50.0%
This parameter allows stopping the drive by generating “R20 GRND INPUT” fault
when the ground fault input current value is above the threshold set in this
parameter.
YES
