Power Electronics SD700 User Manual

POWER ELECTRONICS
SD700FR SERIES
DESCRIPTION OF PROGRAMMING PARAMETERS
59
4.22.3. Subgroup 22.12 – S22.12: LCL Control
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
1 LCL Mode=RUN
G22.12.1/ LCL
filter mode
operation
RUN
POWER
The LCL filter is equipped with a contactor that isolates the capacitors from the
grid and eliminates the stand-by consumption of the filter.
DESCRIP.
FUNCTION
RUN
The contactor is closed with the run command and
opened with the rectifier‟s stop command
Note: if delay IGBT function is enabled, the stop
command is given after the time.
POWER
The contactor is closed when the power level set in
“G22.12.2” is reached. The contactor is opened when the
power is below 0.9x”G22.12.2” and elapsed 60”.
NO
2 Pw RunLCL=20%
G22.12.2 /
Power Run LCL
filter
10%-100%
Allows configuring the power threshold level to open and close the LCL contactor.
NO
