Power Electronics SD700 User Manual

POWER ELECTRONICS
SD700FR SERIES
DESCRIPTION OF PROGRAMMING PARAMETERS
35
Parameter /
Default Value
Name /
Description
Range
Function
Set on
RUN
10 RUN AFTR VFL = Y
G7.10 K/ Run
after occurring
power loss
N
Y
Allows setting of the drive to start automatically when a main power supply loss
occurs and it is recovered again (power supply loss or instant power supply loss).
OPT
FUNCTION
N=NO
The drive will not start after power supply
recovery occurs even the start command is
active. User should deactivate this signal and
activate it again.
Y=YES
The drive starts automatically when power supply
is recovered after power supply loss occurs and if
the start signal is active.
Note: If start / stop control is done by keypad, the drive will not start automatically
after power supply loss occurs and it is recovered again.
YES
11 SPNstr B = OFF
SPIN START TUNE
G7.11 / Accuracy
setting for
Starting by Spin
OFF=0,
1 – 100%
It allows setting the accuracy of the speed searching function when the drive
starts by SPIN mode. Usually, the optimum value is between 2 and 5%. As the
value is lower, more accuracy is required.
YES
12 OFFdly2=OFF
DELAY AFTER STP2
G7.12 / Delay
time for start
command after
stop
OFF=0,
0.1 to
6500.0
Delay time for start command after producing a stop. If the start command is given
after the time set in this parameter has elapsed, the drive will start immediately.
YES
13 STR AFT RST=S
G7.13 / Start
after fault reset
with start
command
N
Y
It allows starting the drive after resetting the fault produced in the equipment,
whenever the start command is activated.
OPT.
FUNCTION
N=NO
After resetting the fault, the drive will not start
although the start command is activated. To start,
the user should deactivate the start command
and activate it again. This operation mode
guarantees a starting controlled by an operator
although the fault is reset. This option is
commonly used in remote controls in order to
increase the safety at the starting.
Y=YES
The drive will start after resetting the fault,
whenever the start command is activated.
YES
14 RPWr OFF = OFF
G7.14 / Power
Off delay
OFF, 0.001
to 9.99
Sets the time period during which the drive maintains the magnetic flux in the
motor after reaching zero speed when stopping.
YES
15 MagneT = OFF
G7.15 /
Magnetization
Time
OFF, 0.001
to 9.99
Sets the period of time during which the motor is being magnetized before the
start.
YES
16 DLY SAR= 0.01
G7.16 /DLY Start
after Run.
OFF, 0.001
to 9.99
Operates with G7.13. Estimates the minimum time that the start order has to be
disabled before starting after the reset.
YES
