POWER ELECTRONICS
SD700FR SERIES
65
Parameter
Screen
Description
Address
Range
Modbus
Range
G3.5
5 REF2 TQ = LOCAL
Torque reference supply 2
40126
NONE
AI1
AI2
AI1+AI2
RES
LOCAL
MREF
PMOT
PID
COMMS
0 to 10
G3.6
6 TQ = +100%
Torque local reference
40127
-250 to +250%
-20480 to
+20480
G4.1.1
1 CNTROL MODE1=1
Main Control Mode
40040
0 to 3
0 to 3
G4.1.2
2 CNTROL MODE2=2
Alternative Control Mode
40041
0 to 3
0 to 3
G4.1.3
3 RESET MODE=Y
Reset from keypad
40039
N
Y
0 to 1
G4.1.4
4 DIGIT I MODE=1
Selection of Digital Inputs configuration
40038
0 to 5
0 to 5
G4.1.5
5 DIGITL IN 1=06
Multi-function Digital Input 1 configuration
40032
00 to 75
0 to 75
G4.1.6
6 DIGITL IN 2=00
Multi-function Digital Input 2 configuration
40033
00 to 75
0 to 75
G4.1.7
7 DIGITL IN 3=00
Multi-function Digital Input 3 configuration
40034
00 to 75
0 to 75
G4.1.8
8 DIGITL IN 4=00
Multi-function Digital Input 4 configuration
40035
00 to 75
0 to 75
G4.1.9
9 DIGITL IN 5=00
Multi-function Digital Input 5 configuration
40036
00 to 75
0 to 75
G4.1.10
10 DIGITL IN6=17
Multi-function Digital Input 6 configuration
40037
00 to 75
0 to 75
G4.2.1
1 SENSOR 1 ?=N
To enable sensor of Analogue Input 1
40268
N
Y
0 to 1
G4.2.2
2 SENSOR 1=l/s
Selection of sensor 1 units
40272
%
l/s
m³/s
l/m
m³/m
l/h
m³/h
m/s
m/m
m/h
Bar
kPa
Psi
m
ºC
ºF
ºK
Hz
rpm
0 to 18
G4.2.3
3 AIN1 FORMAT=V
Analogue Input 1 format
40264
V
mA
0 to 1
G4.2.4
4 INmin1=+0V
Minimum range of Analogue Input 1
40248
-10V to G4.2.6
+0mA to G4.2.6
-10000 to
+10000
0 to +20000
G4.2.5
5 Smi1=+0.0l/s
Minimum range of sensor 1
40254
-3200 to G4.2.7
Engineering Units
-32000 to
+32000
G4.2.6
6 INmax1=+10V
Maximum range of Analogue Input 1
40244
G4.2.4 to +10V
G4.2.4 to +20mA
-10000 to
+10000
0 to +20000
G4.2.7
7 Sma1=+10.0l/s
Maximum range of sensor 1
40250
G4.2.5 to +3200
Engineering Units
-32000 to
+32000
G4.2.8
8 SPD LO1=+0%
Speed for the minimum range of Analogue Input 1
40246
-250% to G4.2.9
-20480 to
+20480
G4.2.9
9 SPD HI1=+100%
Speed for the maximum range Analogue Input 1
40242
G4.2.8 to +250%
-20480 to
+20480
G4.2.14
14 AIN1 LOSS=N
Protection for Analogue Input 1 loss
40266
N
Y
0 to 1
G4.2.15
15 1_Z BAND=OFF
Zero band filter for Analogue Input 1
40270
OFF = 0.0; 0.1 to 2.0%
9 to 163
G4.2.16
16 FILTER1=OFF
Low Pass filter for Analogue Input 1
40274
OFF = 0.0; 0.1 to 20.0%
0 to 200
G4.3.1
1 SENSOR 2 ?=N
Sensor of Analogue Input 2 enable
40269
N
Y
0 to 1
