SD700FR SERIES
POWER ELECTRONICS
96
CONFIGURATION REGISTER
PARAMETERS
FACTORY SETTINGS
SETTING 1
SETTING 2
15 MAC B=80
80
___________________
___________________
16 MAC C=194
194
___________________
___________________
17 MAC D=114
114
___________________
___________________
18 MAC E=X
X
___________________
___________________
19 MAC F=Y
Y
___________________
___________________
G21: Networks – S21.2: MODBUS TCP
1 MIPtout=OFF
MODBUS TCP TOUT
OFF
___________________
___________________
G21: Networks – S21.3: ETHER./IP
1 CONTROL MODE=0
0
___________________
___________________
2 REFEREN.MODE=0
0
___________________
___________________
G22: Rectifier
1 Vdc REF=600 for
Vin=400/480V, 800 for
Vin=525V, 1050 for Vin=690V
600 for Vin=380/480V,
800 for Vin=525V,
1050 for Vin=690V
___________________
___________________
2 Cos phi=1
1
___________________
___________________
3 CAP/IND=CAP
CAP
___________________
___________________
4FREQ RE=2800
2800
___________________
___________________
5 TIME OFF=0.0
0.0
___________________
___________________
8 AD K=0
0
___________________
___________________
9 AD HPF=500
500
___________________
___________________
G22: Rectifier – S22.10: PID Conf.
1 Kp PLL=50.0
10.0
___________________
___________________
2 Ki PLL=50.0
15.0
___________________
___________________
3 Kp Vdc=50.0
10.0
___________________
___________________
4 Ki Vdc=50.0
3.5
___________________
___________________
5 Kp I=50.0
10.0
___________________
___________________
6 Ki I=50.0
10.0
___________________
___________________
G22: Rectifier – S22.11: Protect.
1 DESEQ Iin=NO
NO
___________________
___________________
2 GND FAULT=NO
NO
___________________
___________________
3 TEMP IGBT=LMT
LMT
___________________
___________________
4 Iin=NO
NO
___________________
___________________
5 I lim REC=1.5 x I nominal
drive select
1.5 x I nominal drive select
___________________
___________________
6 T I Limit=0
0
___________________
___________________
7 I Imb=0.0
0.0
___________________
___________________
8 I Gnd=0.0
0.0
___________________
___________________
G22: Rectifier – S22.12: LCL Ctrl
1 LCL Mode=RUN
RUN
___________________
___________________
2 Pw RunLCL=10
10
___________________
___________________
