4.5 7.8 205 180 7.7 60 3.4 - -
5.0 8.2 195 180 7.6 120 4.9 60 3.6
5.5 9.3 180 120 4.6 60 3.5 - -
6.0 10.4 215 180 5.9 120 4.4 60 3.1
6.5 11.5 225 180 6.3 120 4.8 60 3.6
7.0 10.6 220 180 7.9 120 5.4 60 3.6
7.5 12.3 205 180 7.6 120 5.4 60 4.1
8.0 12.5 200 180 7.7 120 5.0 60 3.5
9.0 14.4 200 180 9.1 120 5.9 60 3.9
9.5 15.4 210 180 9.4 120 6.2 60 4.3
10.5 16.0 220 180 9.8 120 6.5 60 4.3
12.0 19.4 210 180 12.5 120 8.1 60 4.9
13.5 23.3 210 180 18.5 120 10.8 60 6.6
15.5 25.5 220 180 13.9 120 9.0 60 6.8
17.5 28.2 225 220 22.4 180 17.0 120 10.9
19.5 30.6 235 220 23.6 180 17.4 120 10.3
21.5 33.5 240 220 26.4 180 19.4 120 11.9
24.0 35.1 230 220 33.4 180 24.3 120 14.4
28.0 48.7 215 180 40.2 120 21.1 60 11.1
30.0 51.6 225 220 50.6 180 38.0 120 23.2
35.0 58.5 200 180 38.0 120 32.6 60 15.7
40.0 68.3 190 180 54.3 120 40.5 60 22.2
45.0 76.2 180 180 66.0 120 49.6 60 29.4
50.0 83.9 165 120 61.9 - - - -
Nozzle Size
100 PSIG Approx. High Approx. High
Nominal Fire Rate Fire By-Pass
Rating GPH GPH (Return) Approx. Approx. Approx. Approx. Approx. Approx.
#2 Fuel Oil 300 PSIG Pressure By-Pass Firing Rate By-Pass Firing Rate By-Pass Firing Rate
By-Pass By-Pass PSIG By-Pass (Return) GPH (Return) GPH (Return) GPH
(Return) (Return) (Return) Pressure Pressure Pressure
Closed Closed Closed PSIG PSIG PSIG
MONARCH
Supply Pressure to Nozzle 300 PSIG at All Rates*
Reduced Firing Rates
HAGO
Nozzle Size
100 PSIG
Nominal
Rating GPH
#2 Fuel Oil
By-Pass
(Return)
Closed
Approx. High
Fire Rate
GPH
300 PSIG
By-Pass
(Return)
Closed
Approx. High
Fire By-Pass
(Return)
Pressure
PSIG By-Pass
(Return)
Closed
Approx.
By-Pass
(Return)
Pressure
PSIG
Approx.
Firing Rate
GPH
Approx.
By-Pass
(Return)
Pressure
PSIG
Approx.
Firing Rate
GPH
Approx.
By-Pass
(Return)
Pressure
PSIG
Approx.
Firing Rate
GPH
Supply Pressure to Nozzle 300 PSIG at All Rates*
Reduced Firing Rates
10.5 17.5 202 150 11.4 120 8.0 90 5.4
11.0 19.3 203 150 11.4 150 11.4 120 7.9
11.5 20.0 192 180 17.8 150 12.8 120 8.5
12.0 20.1 194 180 18.1 150 13.0 120 9.1
12.5 21.6 196 180 18.6 150 13.4 120 8.9
13.0 22.2 205 180 17.8 150 12.9 120 8.8
13.5 23.2 192 180 21.0 150 14.8 120 10.5
14.0 24.0 208 180 18.9 150 13.3 120 8.5
14.5 24.6 207 180 18.6 150 14.1 120 9.2
15.0 26.0 199 180 21.8 150 15.6 120 10.4
16.0 26.8 190 180 24.9 150 18.2 120 11.9
17.0 29.0 206 180 23.4 150 16.9 120 11.5
17.5 29.2 204 180 24.4 150 18.1 120 12.2
18.0 29.8 206 150 20.0 120 15.3 90 11.1
19.0 32.4 202 180 27.8 150 20.2 120 14.1
19.5 33.4 185 150 24.3 120 17.1 90 11.3
20.0 35.2 185 150 26.5 120 18.3 90 12.1
21.0 36.4 190 150 26.2 120 18.8 90 13.1
21.5 37.0 192 150 26.8 120 18.4 90 12.8
22.0 37.3 192 150 26.0 120 19.6 90 13.6
24.0 41.6 190 150 29.7 120 21.7 90 15.1
26.0 42.4 198 150 29.5 120 22.1 90 15.8
28.0 46.0 198 150 31.6 120 23.8 90 17.9
30.0 49.3 196 150 35.9 120 28.3 90 21.6
32.0 53.0 192 150 40.3 120 31.2 90 23.9
35.0 57.1 205 150 40.1 90 26.1 70 22.5
40.0 65.3 198 150 49.3 90 31.9 70 27.8
45.0 74.6 188 150 61.9 90 43.8 70 39.7
50.0 83.0 175 150 73.7 90 51.2 70 46.1
C32
