Power Flame C2-OB - 9. BURNER START UP INFORMATION & TEST DATA

The following information shall be recorded for each burner start up:
Power Flame Model No.
Invoice No. Serial No.
Installation Name
Start Up Date
Start Up Contractors Name
Phone
Name of Technician Performing Start Up
Type of Gas Natural LP Other Fuel Oil Grade No.
9. BURNER START UP INFORMATION & TEST DATA
Oil Firing
High Fire Vacuum Reading at Oil
Pump Inlet ”H.G.
Gas Pressure at Pilot Train Inlet
(If applicable)
Gas Pressure at Pilot Test Tee
(If applicable)
Oil Nozzle Supply Pressure
Low Fire
High Fire
Oil Nozzle Bypass Pressure
Low Fire
High Fire
Power Supply
Volts Ph Hz
Control Circuit Volts
Blower Motor amps at high fire
Remote Oil Pump Motor amps at high
fire
Gas Firing
Gas Pressure at Train Inlet
Burner in Off Position ”W.C.
Gas Pressure at Train Inlet
Low Fire
High Fire
Gas Pressure at Firing Head
Low Fire
High Fire
Gas Pressure at Pilot Test Tee
Power Supply
Volts Ph Hz
Control Circuit Volts
Blower Motor amps at high fire
Net Stack Temperature
Low Fire
High Fire
Combustion Efficiency
Low Fire %
High Fire %
NOx Measured
Low Fire
High Fire
Flame Signal Reading
Pilot (If applicable)
Low Fire
High Fire
GPH Firing Rate
Low Fire
High Fire
CO
2
or O
2
(Specify)
Low Fire
High Fire
Bachrach Scale Smoke Number
Low Fire
High Fire
Over Fire Draft
Low Fire
High Fire
Stack Outlet Test Point Draft
Low Fire
High Fire
Flame Signal Readings
Pilot
Low Fire
High Fire
CO
2
or O
2
(Specify)
Low Fire
High Fire
CO
Low Fire
High Fire
Input Rate BTU/HR
Low Fire
High Fire
Over Fire Draft
Low Fire
High Fire
Stack Outlet Test Point Draft
Low Fire
High Fire
Net Stack Temperature
Low Fire
High Fire
Combustion Efficiency
Low Fire %
High Fire %
NOx Measured
Low Fire
High Fire
C46
Rev.304
