PowerLogic™ Ethernet Gateway 63230-319-204A2
Diagnostics 12/2008
© 2008 Schneider Electric. All Rights Reserved.16
ENGLISH
Serial Port
Frames Sent A counter that increments each time a frame is
sent.
Frames Received A counter that increments each time a frame is
received.
CRC Errors A counter that increments each time a
message is received that has a CRC that does
not match what is calculated. Typically the
result of wiring issues.
Protocol Errors A counter that increments each time an ill-
formed message is received.
Timeouts A counter that increments each time a request
message is sent without receiving a
corresponding response message within the
allowed time. Timeouts are typically the result
of configuration errors or a non-responsive
device.
Inbound Read Messages
"
A counter that increments each time a read
request message is received.
Outbound Read Messages
c
A counter that increments each time a read
request message is sent.
Inbound Write Messages
"
A counter that increments each time a write
request message is received.
Outbound Write Messages
c
A counter that increments each time a write
request message is sent.
Gateway Information
Firmware Version The firmware version that is installed on the
EGX.
System Idle Time A percentage from 0% to 100% indicating the
average processor time that is not being used.
MAC Address The unique Ethernet hardware address of an
EGX.
Serial Number The serial number of the EGX.
Model Number The EGX model number (100).
Hardware Version EGX hardware version.
Manufacture Date Date the EGX was manufactured.
Statistic Description
c
Available when the serial port is in Master mode.
"
Available when the serial port is in Slave mode
