K6 K8 K10 K20 | SERVICE MANUAL
proceed in removing the entire rear panel. (Fig. 35)
(Fig. 35)
Once the rear panel has been removed, remove the RJ45
connector. (Fig. 36)
Unscrew the fans power cables. (Fig. 37)
(Fig. 36)
(Fig. 37)
Now the two fans can be unscrewed from the amplier
chassis by removing the screws indicated in (Fig. 38).
(Fig. 38)
In case of a fault in the fan or in the fan’s driver, please
refer to the table below when ordering the repair kit.
Model Kit
K STD
KT000810.R
K HGT KT000816.R
