6 | LiteMod 4HV | User guide
11 : 2. 2. PL2 pinout
Pin# Symbol Description
1 GND Ground connection
2 HOT +12 V, 200 mA max current draw
3 GND Ground connection
The PL2 molex plug is intended for connecting a fan whose
activation is driven in relation to the temperature.
11 : 2. 3. PL1000, PL3000 pinout
11 : 2.1. PL1 pinout
Pin# Symbol Description
1 L AC Mains: Line input
2 n/c not connected
3 N AC Mains: neutral input
LiteMod4HV - PL1000 (IDC34p)
Pin# Name Type Description Range
Scale
Factor
Impedance
1 SDPWS IN
Power supply shut down. Active High.
Enable enegy save mode (consumption
<1W). Same as pin 34. Same as pin 1 and
34 on PL3000
3,3VDC< VIH <12VDC \ 4,7K
2 READY 1 OUT
Channel 1 PWM state. High when output 1
PWM generation is enabled
VOH= 5VDC / VOL= 1VDC \ 100K
3 RESERVED \ \ \ \ \
4 +5VDC OUT POWER
Regulated +5VDC supply output (+/-5%).
Same as pin 31. Same as pin 4 and 31 on
PL3000
Max current available= 50mA \ \
5 GND POWER
6 IN 1+ IN
Channel 1 balanced input (non-inverting)
3VRMS input for full output
Absolute MAX input= 8VRMS
\
Differential= 3KΩ
Common mode=
3.5KΩ (bal)
Channel 1 unbalanced input ( non-invert-
ing, when shorting pin 7 to GND)
\ 3,5KΩ (unbal)
7 IN 1- IN
Channel 1 balanced input (inverting) \
Differential= 3KΩ
Common mode=
0,95KΩ (bal)
Channel 1 unbalanced input (inverting,
when shorting pin 6 to GND)
\ 1,5KΩ (unbal)
8 GND POWER
9 VOUT1MON OUT Channel 1 output voltage monitor 0-4,5VDC 20V/V 4,5KΩ
10 PROTECT 1 OUT
Channel 1 output stage protection monitor.
Low when output is in protect state
11VDC< VOH <13VDC
0VDC< VOL <1VDC
\
Open Collector -
100KΩ Pullup
11 IOUT1MON OUT Channel 1 output current monitor 0-4VDC 8,35A/V 2,7K
12
TEMPMON
12
OUT
Output stages 1&2 temperature monitor.
Highest temperature between channel 1
and 2 is considered. Same as pin 23
0-5VDC
See
Table
10K
13 +12VDC OUT POWER
Regulated +12VDC (+/-10%) supply output
(for audio circuits). Same as pin 22. Same
as pin 13 and 22 on PL3000
Max current available= 1A \ \
14 -12VDC OUT POWER
Regulated -12VDC (+/-10%) supply output
(for audio circuits). Same as pin 21. Same
as pin 14 and 21 on PL3000.
Max current available= 0,3A \ \
15 MUTE 1 IN
Channel 1 hardware mute. Active low.
Disable output stage PWM generator
VIL (max)=0,2VDC \
47KΩ Internal pull-
up to +5VDC
16 +VCCMON OUT Positive rail bus monitor +4,5VDC MAX 20V/V 4,5KΩ
17 -VCCMON OUT Negative rail bus monitor -4,5VDC MAX 20V/V 4,5KΩ
18 -VCCMON OUT Negative rail bus monitor -4,5VDC MAX 20V/V 4,5KΩ
19 +VCCMON OUT Positive rail bus monitor +4,5VDC MAX 20V/V 4,5KΩ
20 MUTE 2 IN
Channel 2 hardware mute. Active low.
Disable output stage PWM generator
VIL (max)=0,2VDC \
47KΩ Internal pull-
up to +5VDC
21 -12VDC OUT POWER
Regulated -12VDC (+/-10%) supply output
(for audio circuits) Same as pin 14. Same as
pin 14 and 21 on PL3000
Max current available= 0,3A \ \
