powersoft LiteMod 4HV User Manual

Specifications | 25
17
Specifications
Construction
Dimensions 216 x 125 x 42 mm
Weight 1300 g
Aux Supplies
Max aux supply current draw @ +12 V 1000 mA
Max aux supply current draw @ –12 V 300 mA
Max aux supply current draw @ +5V 50 mA
Fan output (temperature controlled) @ +12V 200 mA
Output Power, all channels driven symmetrically
# of channels 4 ch 2 ch 2 ch 1 ch
Conguration SE BTL PTL PBTL
2 Ω 750 W - 2000 W 3000 W
4 Ω 1000 W 1500 W 1500 W 4000 W
8 Ω 750 W 2000 W 800 W 3000 W
70 V 900 W 1200 W 1800 W 2400 W
100 V - 1800 W - 3600 W
Output Power, half channels at -6dB
2 Ω 1100 W - 2600 W
-
4 Ω 1300 W 2200 W 1800 W
-
8 Ω 900 W 2600 W 900 W
-
70 V 1400 W 1200 W 2800 W
-
100 V - 2500 W -
-
Maximum output voltage (typ.) 135 V
peak
270 V
peak
135 V
peak
270 V
peak
Maximum output current (typ.) 50 A
peak
50 A
peak
100 A
peak
100 A
peak
Audio
Gain 26 dB
Frequency Response ( ±1 dB , 1 W @ 8 Ω) 10 Hz - 30 kHz
S/N (20 Hz - 20 kHz A-Weighted @ 8 Ω) 117 dB (A) Typ.
Noise Floor -80 dBV (A) Typ.
Crosstalk Separation (1 kHz) 80 dB Typ.
Input sensitivity 16 dBu
Input impedance 6 kΩ balanced
THD+N (from 0.1 W to 1/2 Power) < 0.08% (0.05% Typ.)
DIM (from 0.1 W to 1/2 Power) < 0.2% (0.05% Typ.)
Damping Factor > 500 @ 1 kHz
Thermal & Environment
Operating temperature &
Humidity
0° to 35° C, 0 to 90% Non condensing
Thermal Dissipation Cooling Plate + Optional Variable Speed Fan
1/8 Max Output Power @ 4Ω
Current Draw @ 230 V 2.6 A
rms
Thermal Loss @ 230 V 400 BTU/h
Current Draw @ 115 V 5.2 A
rms
Thermal Loss @ 115 V 420 BTU/h
Reference Standard
Vibration
EN 60068-2-64: 2008 (Random Test)
EN 60068-2-27:2009 (Shock Test)
EMC immunity EN 55035:2017
EMC emissions EN 55032:2012/AC:2013
EMC other
EN 61000-3-2:2014
EN 61000-3-3:2013
EN 61000-3-11:2000
Safety standards
EN 62368-1:2014
EN 62368-1:2014/AC:2015
AC Mains Power
Power supply
Universal input, regulated Switch Mode with
PFC
Nominal voltage 100-240 V AC @ 50/60Hz
Operating Voltage 85-264 V AC
Power Factor cos > 0.9 @ 4 Ω full power
Consumption
Standby < 1 W (with an aux load < 100 mW)
Idle 14 W @ 100-240 V AC
Rated Load @ 1/8 Max Output
Power
600 W
AC Current Avg./Short Term Nominal 6 A | Max 30 A
Electrical characteristics T
a
= 25° C
(unless otherwise specied)
