Table of contents
1. Important safety instructions iii
2. Importantes instructions de sécurité iv
3. Instrucciones de seguridad importantes v
4. Importanti istruzioni di sicurezza vi
5. Regulatory information vii
6. Electrostatic Discharge (ESD) viii
7. LiteMod 4HV 1
7 : 1.Welcome 1
7 : 2.Unpacking & checking for shipping damage 1
7 : 3.Disposal of the packing material 1
8. Thermal constraints 2
8 : 1.Heatsink per formance 2
9. Electromagnetic Compatibility (EMC) & Safety 3
9 : 1. AC MA INS filter 3
9 : 2.Cabling 3
9 : 3.Ferrite cores 3
9 : 4.Chassis shielding 3
9 : 5.Ear th connection 3
10. Mechanical drawings 4
11. Connections 5
11 : 1.Grounding 5
11 : 2.Bill of connectors 5
11 : 2.1. PL1 pino ut 6
11 : 2. 3. P L10 0 0, PL 30 00 pin out 6
11 : 2. 2. P L 2 pinout 6
11 : 2. 4. PL10 01, PL 3 001 pino ut 9
11 : 3.LED encoding 9
11 : 4.Internal Signal Path Polarity 10
11 : 5.Out pu t C onfigur ation 10
12. Fan installation 12
13. Protections 14
13 : 1.Fan C ontrol 14
13 : 2 .Power supply protections 14
13 : 2.1. Primary AC mains overcurrent protection 14
13 : 2.2. Primary AC mains overvoltage protection 14
13 : 2 .3. P rimar y the rmal pro tec tion 14
13 : 2 .4. Total power limite r 14
13 : 3. Amplifier protections 15
13 : 3 .1. Harm ful signa l pro tec tions 15
14. Cable Kit - KT000349 16
14 : 1.Mains Cable – CB000727 16
14 : 2.Output cable, 4 x SE configuration – CB000731 17
14 : 3.Output cable, 2 x BTL configuration – CB000730 18
14 : 4.Output cable, 2 x PTL configuration – CB000733 19
14 : 5.Output cable, 1 x PBTL configuration – CB000732 20
15. Evaluation Board - KT000291 21
15 : 1.Switch f unc tions 21
16. Support and warranty 24
16 : 1.Ser vice 24
16 : 2.Warrant y 24
16 : 2.1. Retu rn of Go ods 24
16 : 2.2 . Repair or rep lacemen t 24
16 : 2.3. Cost and responsibility of transport 24
16 : 3. Assistance 24
17. Specifications 25
| i
