16
Powerware 9315 (100 kVA--160 kVA) Installation
164200292 REV. E 041500
Installation Checklist
-All packing materials and restraints have been removed from each cabinet.
-Each cabinet in the UPS system is placed in its installed location.
-All cabinets (except stand-alone cabinets) are bolted together.
-A ground bond is installed between all cabinets that are bolted together.
-All switchboards, conduits, and cables are properly routed to the UPS and auxiliary
cabinets.
-Power cables are terminated on bypass terminals (E6---E8 on 480V systems, E13---E15
on all other systems).
-P ower cables are terminated on the CB1 input breaker (E1---E3 on 480V systems,
E13---E15 on all other systems).
-A ground conductor is properly installed.
-If neutral connection is used, no other N---G bonds exist downstream from the UPS.
-Battery cables and harness are terminated on the K2 battery contactor E4 and E5.
-Internal battery cabinet connections have been completed (bus bars, plugs, etc.).
-Air conditioning equipment is installed and operating correctly.
-The area around the installed UPS system is clean and dust-free. (It is recommended
that the UPS be installed on a sealed concrete pad on a sealed concrete floor.)
-Adequate workspace exists around the UPS and other cabinets.
-Adequate lighting is provided around all UPS equipment.
-A 120V service outlet is located within 25 feet of the UPS equipment.
-Each Remote Monitor Panel (RMP) is mounted in its installed location. (OPTIONAL)
-The control wiring for each RMP is terminated inside the UPS cabinet. (OPTIONAL)
-The Remote Emergency Power Off (EPO) device is mounted in its installed location
and its wiring terminated inside the UPS cabinet. (OPTIONAL)
-Summary alarms and/or building alarms are wired appropriately. (OPTIONAL)
-A Relay Interface Module (RIM) is mounted in its installed location and its wiring is
terminated inside the UPS cabinet. (OPTIONAL)
-A remote battery disconnect control is mounted in its installed location and its wiring is
terminated inside the UPS and battery cabinet. (OPTIONAL)
