Powerware 9315 - Figure 20. Remote Monitor Panel (RMP)

40
Powerware 9315 (100 kVA--160 kVA) Installation
164200292 REV. E 041500
WIRES MUST
BE TWISTED
FLUSH MOUNT
SURFACE MOUNT
(FOR HANGING)
Figure 20. Remote Monitor Panel (RMP)
Before installing an RMP, be sure you have prepared the UPS according to the
instructions in Chapter 3.
