Powerware 9315 - Figure 24. Terminal Block Bracket; Figure 25. Wiring an RIM to the UPS

46
Powerware 9315 (100 kVA--160 kVA) Installation
164200292 REV. E 041500
Connect to
Po r t 1 ( D E --- 9 ) o n
Communications Panel
TERMINAL
BL OCK
FUSE
(TB3)
Figure 24. Terminal Block Bracket
TB1
TB2
(ON COMMUNICATIONS
PANEL OF THE UPS)
D E --- 9 C O N N E C T O R
Figure 25. Wiring an RIM to the UPS
