Powerware 9315 (100 kVA--160 kVA) Installation
164200292 Rev. E 041500
Installing an Input Transformer
Before installing the input transformer, be sure you have prepared
the UPS according to the instructions in Chapter 3. The input transformer
cabinet arrives as shown in Figure 15. See Drawing 164200292---6 in Appendix A
for cabinet dimensions.
88.9 mm (3.5 in.)
SWIVEL RADIUS
AIR VENTING
COVER
CABINET
TOP CABLE ENTRY
LOCATION
TOP VIEW
BOTTOM VIEW
JOINING POINTS
for joining to UPS
(see Figure 9)
JOINING POINTS
for joining to other
cabinets
(see Figure 12)
Figure 15. Input Transformer Cabinet
