Powerware 9315 - Page 32

26
Powerware 9315 (100 kVA--160 kVA) Installation
164200292 REV. E 041500
CABINET BASE
(side view)
(top view
FRONT
of bases)
GROUNDING CABLE
HARDWARE REMOVED
BEFORE PLACING LUG
OVER GROUND STUD
PERMANENTLY
ATTACHED
HARDWARE
UPS
CABINET
BASE
OPTIONAL
CABINET
BASE
OPTIONAL
CABINET
UPS
CABINET
Figure 13. Cabinet-to-Cabinet Grounding --- Method A
(top view
of bases)
CABINET BASE
FRONT
(side view)
GROUNDING BAR
HARDWARE REMOVED
BEFORE PLACING LUG
OVER GROUND STUD
PERMANENTLY
ATTACHED
HARDWARE
OPTIONAL
CABINET
BASE
OPTIONAL
CABINET
BASE
OPTIONAL
CABINET
OPTIONAL
CABINET
Figure 14. Cabinet-to-Cabinet Grounding --- Method B
