Chapter 5 Function parameter
64
If 1 is selected, when the analog input is less than the minimum input, the setting
corresponding to the analog amount is 0.0%.
HDI Minimum pulse input
frequency
HDI Minimum pulse input
frequency setting
HDI Maximum pulse
input frequency
HDI Maximum pulse
input frequency setting
This group function code is used to set the relationship between DI5 pulse frequency and
its corresponding setting.
Pulse frequency can be inputted into the inverter only through DI5 channel. The
application on this group of functions is similar to curve 1, please refer to the description of
curve 1.
Set software filter time for DI terminals status. For the application that input terminals are
vulnerable to interference and cause the accidental operation, you can increase this parameter so
as to enhance the anti-interference ability. However, the increase of filter time will cause DI
terminal slow response.
Filtering time of panel potentiometer
Filter time of pulse input
DI terminal
valid mode
selection 1
DI1 terminal active status setting
DI2 terminal active status setting (0 to
1, as above )
DI3 terminal active status setting (0 to
1, as above )
DI4 terminal active status setting (0 to
1 , as above)
DI5 terminal active status setting (0 to
1, as above)
DI terminal
valid mode
selection 2
DI6 terminal active status setting
DI7 terminal active status setting
(0 to 1, as above)
Hundreds digit, thousands digit and ten thousands
digit reserve
Used to set the digital input terminal active status mode. If high level is selected as active,
it is active when the corresponding DI terminal and COM are connected, disconnected for
inactive. If low level is selected as active, it is inactive when the corresponding DI terminal and
COM are connected, disconnected for active.
Used to set the inverter's delay time for the change of DI terminal status Currently only
DI1, DI2, DI3 terminals can set the delay time function.
Define the input terminal repeat
0:Unrepeatable；1:Repeatable
