Powtran PI160 Series User Manual

Chapter 5 Function parameter
93
Chapter 5
E1.02
2-stage speed setting 2X
-100.0% to 100.0%
0.0%
☆
E1.03
3-stage speed setting 3X
-100.0% to 100.0%
0.0%
☆
E1.04
4-stage speed setting 4X
-100.0% to 100.0%
0.0%
☆
E1.05
5-stage speed setting 5X
-100.0% to 100.0%
0.0%
☆
E1.06
6-stage speed setting 6X
-100.0% to 100.0%
0.0%
☆
E1.07
7-stage speed setting 7X
-100.0% to 100.0%
0.0%
☆
E1.08
8-stage speed setting 8X
-100.0% to 100.0%
0.0%
☆
E1.09
9-stage speed setting 9X
-100.0% to 100.0%
0.0%
☆
E1.10
10-stage speed setting 10X
-100.0% to 100.0%
0.0%
☆
E1.11
11-stage speed setting 11X
-100.0% to 100.0%
0.0%
☆
E1.12
12-stage speed setting 12X
-100.0% to 100.0%
0.0%
☆
E1.13
13-stage speed setting 13X
-100.0% to 100.0%
0.0%
☆
E1.14
14-stage speed setting 14X
-100.0% to 100.0%
0.0%
☆
E1.15
15-stage speed setting 15X
-100.0% to 100.0%
0.0%
☆
The multi-stage command can be used as frequency source, can also act as the set source
of process PID. The dimension of multi-stage command is the relative values and its range is
from -100.0% to 100.0%, when it acts as the frequency source, it is the percentage of maximum
frequency; due to the PID reference is originally as a relative value, therefore the multi-stage
command acts as the set source of PID and does not need dimension conversion.
The multi-stage command needs to switch according to the different states of
multifunction digital DI, please refer to F1 group for specific instructions.
E1.16
Simple PLC
running mode
Stop after single running
0
0
☆
Hold final value after single running
1
Circulating
2
The figure is the schematic diagram of Simple PLC as the frequency source. For Simple
PLC as the frequency source, the positive or negative value of E1.00 to E1.15 determines the
running direction, the negative value indicates that the inverter runs at the opposite direction.
As the frequency source, PLC operates in three modes, including:
0: Stop after single running
After the inverter completes a single cycle, it will automatically shut down , the running
command must be given before restart.
1: Hold final value after single running
After the inverter completes a single cycle, it will automatically maintain the frequency
and direction of the last stage.
2: Circulating
After the inverter completes a cycle, it will automatically start next cycle, and stop till the
stop command is given.
