Measurement Mode Display Structure
Press Key 8 to display the following:
Display1B (if optional humidity sensor is fitted)
Press Key 8 to display the following:
Where:
Date (19
th
day of December)
Press Key 8 to display the following:
Display 3
Where:
Signal (mV) from sensor connected
to Pin 1 on the 15 pin D Connector.
Signal (mV) from sensor connected
to Pin 2 on the 15 pin D Connector.
Signal (mV) from sensor connected
to Pin 3
on the 15 pin D Connector.
Note. Due to limits on the display,
the letter C is not displayed.
Signal (mV) from sensor connected
to Pin 4 on the 15 pin D Connector.
Signal (mV) from sensor connected
to Pin 5 on the 15 pin D Connector.
See Environmental Sensor Inputs on page 12.
Press key 8 to return to Display 1A in
Measurement Mode.
Where:
Date (19
th
day of December)
Press Key 8 to display the following:
Display 3
Where:
Signal (mV) from sensor connected
to Pin 1 on the 15 pin D Connector.
Signal (mV) from sensor connected
to Pin 2 on the 15 pin D Connector.
Signal (mV) from sensor connected
to Pin 3 on the 15 pin D Connector.
Note. Due to limits on the display, the
letter C is not displayed.
Signal (mV) from sensor connected
to Pin 4 on the 15 pin D Connector.
Signal (mV) from sensor connected
to Pin 5 on the 15 pin D Connector.
See Environmental Sensor Inputs on page 12.
Press key 8 to return to Display 1B in
Measurement Mode.
The record number resets each time the instrument starts or when the memory is cleared. It
counts up to 9999 and then resets automatically to 1. The internal EGM-4 memory allows
data storage of up to 1,000 records. Please note, when the memory is full, it overwrites
the oldest records.
