Alarm Acknowledgment
The FLOREX is provided with the output (Relay/SSR) facilitating “hard” alarm for Flow Rate as well as Flow Total. That is, if
any or both the alarms are activated (alarm condition is occurred), the output (Relay/SSR) associated with their respective
alarms gets energized and sounds the buzzer/hooter.
The output (Relay/SSR) remains energized until the alarm condition is automatically / manually removed, by Auto Reset or the
user manually acknowledges the alarm condition by pressing the Alarm Acknowledgment (ACK) key
Note that upon pressing this key, the Alarm output switched OFF but the Alarm LED indications will remain continue until the
Alarm condition is removed. However, if the Alarm condition is not removed, the FLOREX continues to indicate the alarm
status by flashing the alarm status LED indicators. If the Alarm condition is removed prior to acknowledging the alarm, the
FLOREX will automatically switched OFF the alarm output and alarm indication. If the Alarm condition is removed after
acknowledging the alarm, the FLOREX will activate the alarm only if new alarm condition will occur.
STORAGE OF MIN. & MAX. FLOW RATE
The FLOREX has a unique feature of view and store the Minimum and Maximum value of measured Flow Rate. This facilitates
user to view the Maximum (Overshoot) and Minimum (undershoot) of Flow Rate from its present value. These values can be
viewed by entering into Operator Page while the FLOREX is in MAIN Display Mode if this feature is enabled under supervisory
level.
Step through the following sequence to View and Reset the Minimum and Maximum value of Flow Rate, if this facility is
enabled under supervisory level.
1. Press SCROLL key from MAIN Display until the Lower Readout displays
Notice that the Right Hand side of the Lower Readout shows the stored Minimum value of Flow Rate.
2. Press SCROLL key once again. The Lower Readout now displays
Notice that the Right Hand side of the Lower Readout shows the stored Maximum value of Flow Rate.
Issuing Min. / Max. Reset Command
Further, these stored values can be Reset by issuing the ‘Reset Command’. In Reset, the stored values of Minimum and
Maximum Flow Rate get erased and overwritten with the present value of Flow Rate. The ‘Reset Command’ can be locked
under supervisory level and will be effective only if it is unlocked at operator level.
1. Press Operator (OPR) key to enter into Operator Page from MAIN Display and keep pressing ENTER key until the Lower
Readout displays Reset Min./Max. Command
2. Use UP key to set the option ‘No’ to ‘Yes’. The Lower Readout displays
3. Press ENTER key to register ‘Yes’ Command. The Lower Readout now displays
4. Use UP/DOWN key to adjust the value of the Passcode. Notice that this Passcode value should match with the value set
for the ‘Supervisory Passcode’ on Utility Page.
5. Press and release ENTER key.
The set value is registered and if matched with the ‘Supervisory Passcode’, the stored Min./Max. Value of Flow Rate will get
erased and the present value of Flow Rate is stored as both Min./Max value of Flow Rate.
Notes:
1. The storage and view of Minimum & Maximum value of Flow Rate is available as long as this feature is Enabled on Supervisory Page. If
this feature is disabled on Supervisory Page, the storage and view of Minimum & Maximum value of Flow Rate function will not be
available.
MIN. FLOW RATE
0
MAX. FLOW RATE
0
RESET MIN. MAX.>
No
RESET MIN. MAX.>
Yes
PASS CODE >>
0
User Manual
FLOREX
5
