16. Connect the frame ground wire to the treadmill frame, Make sure to route the cable
using the frame cable clips to secure the able in position. Securely tighten the mounting
screw to ensure very good electrical connectivity.
17. Connect the Lift Motor connector to the INCLINE connector on the power control mod-
ule. Make sure to route and use the frame cable clips to safely secure the cable away
from the jack screw.
18. Connect the Lift Motor connector to the LIFT connector on the motor control module.
Make sure to route and use the frame cable clips to safely secure the cable away from
the jack screw.
19. Return the treadmill to the upright position.
20. Level the Treadmill.
21. Install the hood.
22. Plug
1
in the power cord and Switch the input power to ON.
23. Verify the treadmill incline operation through the full range of motion. Do the - INCLINE
TEST diagnostic test.
24. Verify treadmill operation (see ) and return to service.
See Also
"Replacement Procedures" on page 48
"Lift Motor Calibration" on page 43
1
Device power cord connector or electrical cable male connector that is inserted into an elec-
trical receptacle "outlet" (also called the plug-in).
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 70
6 Replacement Procedures
Incline Lift Motor Replacement
