Drive Motor Replacement
About
This procedure provides instruction to remove and replace the Drive Motor.
Procedure
Review entire procedure before starting.
1. Switch the input power OFF and unplug
1
the power cord.
2. Remove the front hood.
3. Disconnect the drive motor power cable connector from the OUTPUT connector on the
power control module.
TIP: Remove the MC
2
fasteners so that the MC module can be raised to allow easy
access to disconnect and connect the I/O
3
connectors.
4. Remove the drive belt. It is recommended that you walk the belt off the smaller drive
motor pulley.
1
Disconnect a device power cord plug or cable connector from the power receptacle or outlet.
2
Motor controller or motor controller module
3
Input and Output Interface.
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 59
6 Replacement Procedures
Drive Motor Replacement
