6. Remove the two screws and remove the circuit breaker. Keep fasteners for replace-
ment installation.
7. Set the replacement AC line filter in its mounting position with the three terminals facing
the circuit breaker and secure with previously removed screws.
8. Re-attach wire connections as follows for the 120 VAC
1
and 240 VAC models:
a. On 120 Vac and 240 Vac treadmills, connect the blue wire from the power control
module to the L1 terminal on the LOAD side of the AC line filter and the brown
wire from the power control module to the L2 terminal on the LOAD side of the
AC line filter.
b. On 120 Vac treadmills, connect the blue wire from the input module to the L1 ter-
minal on the LINE side of the AC line filter, the brown wire from the circuit breaker
to the L2 terminal on the LINE side of the AC line filter and the green/yellow wire
to the (non-insulated) terminal mounted directly on the line filter case.
c. On 240 Vac treadmills, connect the blue wire from the circuit breaker to the L1 ter-
minal on the LINE side of the AC line filter, the brown wire from the circuit breaker
to the L2 terminal on the LINE side of the AC line filter and the green/yellow wire
to the (non-insulated) terminal mounted directly on the line filter case.
9. Set the AC input panel in its mounting position and install using the previously removed
fasteners.
10. Plug
2
in the power cord and Switch the input power ON.
11. Verify treadmill operation per "" and return to service.
.See Also
"Replacement Procedures" on page 48
1
voltage in an alternating current circuit
2
Device power cord connector or electrical cable male connector that is inserted into an elec-
trical receptacle "outlet" (also called the plug-in).
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 76
6 Replacement Procedures
Line Filter Replacement
