This option is strictly a hardware option. No HMI Factory Configuration is needed.
Green Light – In Cycle
OFF indicates the following information:
The bagger is not ready for the next cycle to begin due to a fault condition, power is removed, etc.
FLASHES at a steady rate, light is on for 0.5 seconds and off for 0.5 seconds, to indicate the follow-
ing:
The bagger is ready to cycle and is WAITING for a cycle start input from either the operator (Foot
Switch, Optical Palm Buttons, Cycle Start) or a Filling Machine (Filler Done Input).
STEADY ON indicates the following:
The bagger is in cycle. A bagger cycle consists of the following general functions:
1. Seal the existing bag.
2. Separate the sealed bag from the web.
3. Feed out a new bag.
4. Open the new bag for filling.
Note: Filling of the opened bag is a separate operation and is not part of the bagger cycle.
Red Light – Fault
This light is steady ON if the bagger has an active fault condition. A fault is a condition that detects a significant
problem and stops the machine if it is cycling. The fault condition must be corrected and reset before the next
cycle can be initiated.
Power-up Lamp Test
When master control power is turned on the Stack light tower will go through a lamp test sequence for 4 seconds
to verify that the each light is functioning properly. The sequence is:
Green On
Red Off
Green On
Red On
Both Off
Both On
Test Done
THEORY OF OPERATION
INTRODUCTION
1-9
