18 Hardware and Software Set-Up and Testing
m. Press the Sequence button repeatedly until the arm is
aligned over the Output Bin.
n. Press the Pick button. The CD will drop into the default
Output Bin.
o. Press the Pick button again. The CD will be picked up
out of the Output Bin.
p. Press the Sequence button to rotate the Robotic Arm to
the next Input/Output Bin. Press Pick to drop the CD
into the bin and press Pick once again to pick the disc
from the Bin. Repeat this until all Bins have been tested.
q. Press the Pick button. The CD will drop into the
Input Bin.
You have now completed the Hardware Test and Printer
Alignment. Continue on to the Software Installation.
E. SOFTWARE INSTALLATION
Once you have properly set up your Duplicator and optional
CD printer, the next step is to install the appropriate software on
your PC that you'll need for duplicating and printing.
There are two software programs to install: (1) the printer
driver software, and (2) the CD duplicating application software
called PrimoDVD 2.0. Install the software as follows:
1. Install the printer driver software according to the
instructions in that unit's Operator's Manual.
2. Install PrimoDVD 2.0 software as follows:
a. Close down all other software applications.
b. Insert the included CD into your computer's CD-ROM
drive. In most computers the software will auto-boot.
If it does, proceed to Step 3 below. If it does not, follow
these steps:
c. Double-click the My Computer Icon, then double-click
the icon of the appropriate CD drive containing the
Software Installer disc.
3. Click the Install icon for PrimoDVD 2.0.
4. Click the appropriate install icon for the language you wish
the software to display.
5. The Primo Splash Screen will appear. Click Next.
6. The license agreement screen is displayed. After reading it,
press Ye s to continue or No to leave the program.
