Primes PowerLossMonitor PLM Series User Manual

28
Revision 01/2019 EN
PowerLossMonitor PLM
35,0(6
15 Technical data
Measurement parameters PLM 2 PLM 10 PLM 20 PLM 40
Max. laser power 2kW 10kW 20kW 40kW
Resolution temperature measure-
ment
0,001K
Resolution power measurement 1W
Supply data PLM 2 PLM 10 PLM 20 PLM 40
Power supply, DC 24V±5%
Current demand < 800mA
Max. cooling water pressure 3bar 4bar 5bar 5bar
Recommended cooling water flow
rate
1 – 4l/min 7 – 12l/min 10 – 22l/min 20 – 37l/min
Cooling water temperature T
in
1)
Dew point temperatur <T
in
<30°C
1)
Please contact PRIMES in advance in case you intend not to work within this specification.
Communication PLM 2 PLM 10 PLM 20 PLM 40
Interfaces 2 x RS485
1 x USB
2 x RS485
1 x USB
2 x RS485
1 x USB
1 x RS485
1 x USB
Dimensions and weight PLM 2 PLM 10 PLM 20 PLM 40
Dimensions (LxWxH)
without connections
300 x 200 x
80mm
300 x 200 x
80mm
300 x 200 x
80mm
304 x 200 x
146mm
Weight, approx. 3.8kg 3.8kg 3.8kg 6.7kg
