10 70284701
Section 3 Troubleshooting
To reduce the risk of electric shock, fire, explosion, serious injury or death:
• Disconnect electric power to the tumbler before servicing.
• Close gas shut-off valve to gas tumbler before servicing.
• Close steam valve to steam tumbler before servicing.
• Never start the tumbler with any guards/panels removed.
• Whenever ground wires are removed during servicing, these ground wires must be
reconnected to ensure that the tumbler is properly grounded.
W002
WARNING
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
3. MOTOR OVERLOAD PROTECTOR CYCLES REPEATEDLY
4. MOTOR RUNS BUT CYLINDER DOES NOT TURN
5. MOTOR DOES NOT STOP
POSSIBLE CAUSE TO CORRECT
Incorrect voltage • Refer to Installation Manual for electrical requirements.
Clothes load is too large. • Remove part of load.
Clothes cylinder is binding. • Check cylinder for binding.
Inadequate wiring. • Electrician should verify that wiring and voltage is
adequate.
Inadequate make-up air. • Refer to Installation Manual for make-up air
requirements.
Lint buildup around tumbler, poor maintenance. • Clean lint accumulation on and around the motors.
Broken, loose or incorrect wiring. • Refer to wiring diagram.
POSSIBLE CAUSE TO CORRECT
Broken cylinder belt. • Replace cylinder belt.
Cylinder is binding. • Check cylinder for binding.
POSSIBLE CAUSE TO CORRECT
Inoperative door switch. • Test switch and replace if inoperative.
Inoperative coin drop. • Test coin drop and replace if inoperative.
Incorrect wiring. • Refer to wiring diagram.
Electronic control inoperative. • Replace electronic control.
Inoperative motor relay. • Test relay and replace if inoperative.
